51.2V 200Ah Rack-Mounted LiFePO4 Battery RK48200-L
Features:
- LiFePO4 battery with great safety and reliability
- Automotive-grade technology and processes
- Support series connection
- Customizable communication protocols
Parameters
| Model | RK48200-L |
| Rated Capacity | 200Ah |
| Rated Voltage | 51.2V |
| Energy | 10240Wh |
| Standard Charge Current | 100A |
| Max. Charge Current | 100A |
| Charge Cut Off Voltage | 58.4V |
| Standard Discharge Current | 100A |
| Max. Continuous Discharge Current | 100A |
| Max. Pulse Discharge Current | 150A |
| Max. Modules in Parallel | 15pcs in parallel |
| Communication | RS485/RS232/CAN |
| Charge Temperature | 0 to 45ºC |
| Discharge Temperature | -20 to 60ºC |
| Storage Temperature | 0 to 40ºC |
| Dimension | 468*480*235mm |
| Weight | 80kg |
CAN'T FIND WHAT YOU WERE LOOKING FOR?
You May Also Like
FAQ
Rack-mounted LiFePO4 batteries typically have a wide operating temperature range, allowing them to function effectively in various climates. The specific temperature range may vary depending on the manufacturer, but they are designed to operate in both high and low temperature conditions.
Yes, while primarily designed for stationary applications, rack-mounted LiFePO4 batteries can be used in certain mobile or portable setups. However, their size and weight may limit their practicality for highly mobile applications, and alternative form factors may be more suitable in those cases.
Yes, rack-mounted LiFePO4 batteries can be connected in parallel or series to achieve higher capacity or voltage levels, respectively. This allows for greater flexibility in system design and the ability to meet specific energy storage requirements.
Yes, these batteries are designed to be compatible with various power management systems and can be integrated into existing infrastructure seamlessly. They can be connected to inverters, charge controllers, and other power management devices to ensure efficient energy flow and utilization.
